New Square LED Wall Washer(12pcs LED)

Products name, Part No



WW-I-4020---12 PCS LED,1W high power led, Pure white, Voltage: AC100-240V

WW-I-4017---12 PCS LED,1W high power led, Pure white,Voltage:AC100-240V

WW-I-4021---24PCSLED, 1W high power led, Pure white, Voltage: AC100-240V

WW-I-4018---24PCSLED, 1W high power led, RGB, Voltage: AC100-240V

WW-I-4022---36PCSLED, 1W high power led, Pure white, Voltage AC100-240V

WW-I-4019---36PCSLED, 1W high power led, RGB, Voltage: AC100-240V

Product Introduction:



We use 1W high power LED as light source for new Square LED Wall Washer. It has features, of novel appearance, low consumption, long lifespan (fifty thousand for average life), resistance impact, High reliability, environment-friendly, soft light, high brightness and so on. This new type of led wall washer made up of two parts, first part is light body and the other one includes power supply and controller box, which makes this wall washer different with other wall washers so that let it have good heat-dissipating function.

Single color:

Pure white, warm white, red, green, blue, Viewing angle:30°



RGB color:

Viewing angel is 50°,built-in 13 kinds of light effect, also can separately connect DMX console, DMX controller box to achieve the color change control in whole or segments, such as red, green, blue, jump change, gradual, flicker etc. Totally 14 types. It is with digital display window and control buttons to let the customers adjust stand-alone mode more convenient.

Technical Parameters:

12LED Pure white Color Second-Generation Square LED Wall Washer luminous intensity diagram:

24 LED Pure white Color Second-Generation Square LED Wall Washer luminous intensity diagram:

36 LED Pure white Color Second-Generation Square LED Wall Washer luminous intensity diagram:

Dimension diagram





12 LED Second-generation Square wall washer

24 LED Second-generation Square wall washer

36 LED Second-generation Square wall washer

Diagram for installation and connection



1. High voltage single color wall washer, can be lighted up with power on

2. High voltage RGB color Square wall washer connection method.

Attention!



1. Please consider about "the working condition", the lamp can not be put in water for long time



2. Each RGB wall washer takes up 3 DMX addresses, the first wall washer's address plus 3 is the address for the next one.



3.If you want all connected wall washers to change colors together, you should set the same address for all the washers



4. Please set the address from smaller to bigger. The maximum address of RGB wall washer should be less than 510. There should be only one main flood light as a master (the flood light works in main control mode, control box or control console).



5.When there are many  wall washer  connected together, the connections please refer to the connection diagram.



6.The connection cable between two controllers, or between console and signal amplifiers. It can't exceed 100m; The distance between the first signals amplifier or console and the last flood light can't exceed 100m.
